Razorset Slitting Upgrade

Upgrade Applications

Applies to all MarquipWardUnited slitter/scorers that use conventional slitting systems and employ top and bottom tooling.

Upgrade Description

This upgrade replaces the conventional shear type top and bottom slitting blades with a thin-blade slitting concept called Razorset®.The Razorset slit blade is driven at high speeds into the moving corrugated board from a position over the web. The blade is embedded into a slotted bottom anvil roll that provides support for the web as it is cut. The result is a very clean, square edged slit. The upgrade includes linear bearing rails and tracks for lower rollers, linear bearing tracks for slit heads, a third lockdown block, a wick lubrication oiling system, and an automatic sharpening device.

Upgrade Features

• Improved quality of slit
• Reduced maintenance
• Easy installation
• Snap-out type wick change system
• Updated air and festoon system
• New grinding system

Upgrade Benefits

• Razorset slit board is much cleaner, increasing converting productivity and improving print quality
• Razorset slitting eliminates edge delamination, significantly increasing corrugator speeds
• Razorset slit board improves converting efficiency, reducing feed table jams and wash-ups
• Razorset slit board cures more quickly, providing greater stacking performance
• Razorset slid board edges are virtually perfect, improving product aesthetics
